U-30T Pull Down Type Press
Basic Attributes
- Model U-30T
- Press Capacity 300 kN
- Stroke Length 20x25x30 mm
- Max. S.P.M. 600x550x500 S.P.M.
- Min. S.P.M. 180 S.P.M.
- Die Height 185-215x183-213x180-210 mm
- Die Height Adjustment 30 mm
- Slide Area 550x400 mm
- Bolster Area 550x400x50 mm
- Bolster Opening 100x500 mm
- Main Motor Power 4.0x4 kW×P
- Machine Weight 2.8 ton
Description
Main Features of U-30T Pull Down Type Press
- The structure adopts ductile iron technology QT700-2, with high rigidity, light structure and good thermalbalance, etc.
- Double linkage structure, the slide groove distance is as long as 800mm, improving the eccentric loadcapacity of the slider.
- The sliding running structure adopts high quality alloy copper material combined with sliding bearing, withreasonable clearance control, high accuracy holding and silent
- Reverse air pressure damping technology, smooth running, can be used with air vibration pads.
- Servo die height adjustment with automatic mold locking system, small accuracy change in high-speedmovement, easy to adjust and fast.
- Human-machine interface microcomputer control, intelligent factory supporting access.
Dimension of the U-30T Pull Down Type Press
Main Specifications of U-30T Pull Down Type Press
[@@Specification]
Finished Products Produced By U-30T Pull Down Type Press
